產品展示
韓國LS(LG) 電磁接觸器(MC)
產品名稱
LS (LG)微型斷路器
產品特點
BKN 1/2/3P 1/2/3/4/6/10/16/20/25/32/40/50/63A IEC-60898 IEC-60947商檢局認證R41269 啟斷容量6/10KA 體積小、鋁軌式、匯流排、警報開關、輔助接點等附件,另有斷路器專用分電箱,歡迎詢問。
產品說明
General description for residential breakers
Miniature Circuit Breakers
DIN rail mounting
45mm slot size
17.8mm width per pole
-
Type BKN-b
EC60898 type MCB1 to 4pole up to 63A & 10kA -
Type BKN
EC60898 type MCB
1 to 4pole up to 63A & 6kA
Bolt on
50mm slot size
60mm depth
-
Type BF
American type MCB
1 to 3pole up to
100A & 10kA (BF-a)
100A & 5kA (BF-c)
50A & 2.5kA (BF)
100A & 10kA
(BFa-LUG; 3 pole only)
Bolt on
36mm slot size
42mm depth
-
Type BS
Economic type MCCB
2 & 3pole up to 30A & 1.5kA -
Type BF-Plug
1 to 3pole up to 50A, 10kA
Connection by lug terminal
TYPE
TYPEA(2P無蓋)
TYPEB(2-4P無蓋)
TYPE C (2-4P有蓋)
